The Ubiquiti UniFi Network Video Recorder Instant Kit (UNVR-Instant-Kit) is a complete small-site surveillance package. Ubiquiti describes the kit as “(1) UniFi Protect NVR Instant with (4) G5 Turret Ultra cameras and (1) 1TB HDD”, so the recorder, the cameras and the drive are matched from the outset. The NVR Instant has six GbE PoE downlink ports, which powers all four cameras directly with room for two more, and an HDMI output for a wall display. It suits a shop, workshop, small warehouse, office or home where four fixed exterior or interior views are enough.
Key features
- Recorder plus four 2K G5 Turret Ultra cameras and a 1 TB HDD as a matched set
- Six GbE PoE RJ45 downlink ports with a 40W PoE budget, plus a GbE RJ45 uplink and an HDMI port for Viewport
- Manages up to (15) HD, (8) 2K or (6) 4K cameras, and up to 50 access hubs
- Cameras offer 30 m IR night vision, a 102.4° horizontal field of view, IP66 weatherproofing and IK04 tamper resistance
- Smart detections for people, vehicles and animals
- Data protection and Vantage Point supported; runs UniFi Protect, UniFi Access and UniFi Connect
- Internal 60W power supply, so no external brick at the recorder
- NDAA compliant
Specifications
| Model | UNVR-Instant-Kit |
| NVR dimensions | 220 x 220 x 47 mm (8.7 x 8.7 x 1.9″) |
| NVR weight | 1.04 kg (2.3 lb) |
| Networking interface | (1) GbE RJ45 uplink, (6) GbE PoE RJ45 downlink, (1) HDMI (Viewport) |
| Managed cameras | (15) HD, (8) 2K, (6) 4K |
| Storage | (1) 3.5″ drive bay; 1 TB HDD supplied with the kit |
| Processor | Quad-core ARM Cortex-A55 at 1.7 GHz |
| Memory | 4 GB |
| Display | 1.14″ screen |
| PoE budget | 40W (PoE 15.4W per port, 44-57V) |
| Power method | Universal AC input, 100-240V AC, 1.5A max, 50/60 Hz |
| Power supply | AC/DC, internal, 60W |
| Max. power consumption | 9W |
| Camera resolution | 2K, 4MP 2688 x 1512 (16:9), up to 30 FPS |
| Camera sensor | 1/2.4″ CMOS, fixed focal length |
| Camera field of view | H: 102.4°, V: 54.9°, D: 120.6° |
| Camera IR night vision | 30 m (98 ft) |
| Camera weatherproofing | IP66, IK04 |
| Camera power method | PoE, 37-57V DC, 4W max. |
| Operating temperature | NVR: 0 to 40°C; camera: -30 to 50°C |
| Certifications | FCC, IC, CE, electrical safety |
| NDAA compliant | Yes |
The UniFi Network Video Recorder Instant Kit is a straightforward way to stand up a four-camera UniFi Protect site from a single part number.
