UACC-CHIME-POE $185.00 Save:$22.00(11%)
Description

The Ubiquiti UniFi PoE Smart Chime (UACC-Chime-PoE) is a network-powered indoor chime for UniFi Protect doorbells and UniFi Access door entries. Because it takes both data and power from a single Ethernet run, it can be sited wherever it will actually be heard — a hallway, a workshop, a back office or an upstairs landing — rather than being tied to existing doorbell wiring. The built-in speaker and buzzer give an audible alert, and the R/G/B/W LEDs give a visual one for noisier rooms.

Key features

  • Audible doorbell and door-entry notifications via speaker and buzzer
  • R/G/B/W status LEDs for visual notification
  • Single 10/100 MbE port carrying data and power, so no separate mains outlet is needed at the chime
  • Low 3W maximum draw
  • ESD protection of ±8 kV air and ±4 kV contact
  • NDAA compliant; CE, FCC and IC certified

Specifications

Model UACC-Chime-PoE
Dimensions (device) ⌀62 x 54 mm (⌀2.5 x 2.1″)
Dimensions (in-wall mount) ⌀89 x 63.1 mm (⌀3.5 x 2.5″)
Dimensions (on-wall mount) ⌀62 x 20.2 mm (⌀2.5 x 0.8″)
Weight (device) 158 g (5.6 oz)
Weight (in-wall mount) 91 g (3.2 oz)
Weight (on-wall mount) 28 g (1 oz)
Enclosure material Polycarbonate, aluminium alloy
Mount material Polycarbonate, zinc alloy
Networking interface 10/100 MbE port
Speaker Yes
Buzzer Yes
Power method PoE
Supported voltage range 44-57V DC
Max. power consumption 3W
ESD protection Air: ±8 kV, contact: ±4 kV
LEDs R/G/B/W
Buttons (1) factory reset
Operating temperature 0 to 40°C (32 to 104°F)
Operating humidity 10 to 90% non-condensing
Certifications CE, FCC, IC
NDAA compliant Yes

The UniFi PoE Smart Chime is adopted and configured from your UniFi console like any other UniFi device.
