Ubiquiti U5G-MAX-OUTDOOR $1,250.00 Save:$133.00(10%)
Description

The Ubiquiti UniFi 5G Max Outdoor is the weatherproof version of Ubiquiti’s UniFi cellular modem. Ubiquiti describes it as “a full-performance 5G (3.4 Gbps) modem for UniFi consoles and Cloud Gateways, designed for outdoor use with directional antennas, remote SIM, and dual SIM for seamless failover”. Mounting the modem outside — on a wall, a pole or a mast — puts the antennas where the signal actually is, which is usually the difference between a workable cellular WAN and a marginal one at a rural site, a construction compound or a metal-clad building. A single Ethernet run back to a UniFi PoE port carries both power and data.

Key features

  • Outdoor-rated 5G NR and LTE modem with a directional antenna system, peak 9 dBi over an 85° x 85° beam
  • Peak 5G NSA data speed of 3.4 Gbps downlink and 560 Mbps uplink as published by Ubiquiti
  • Dual SIM — one Nano SIM slot plus a second slot taking either a Nano SIM or eSIM — for carrier failover
  • Remote SIM, as listed by Ubiquiti for this model
  • Single 2.5 GbE RJ45 port for data and power; power method is PoE at up to 14.5W
  • IPX6 weatherproofing, rising to IP67 when fitted with the cable-gland door kit
  • Wide operating range of -40 to 65 °C, suited to exposed installations
  • Wall and pole mounts included; aluminium alloy and UV-stabilised polycarbonate enclosure
  • Works with UniFi consoles and Cloud Gateways and is managed in the UniFi Network application; NDAA compliant

Specifications

Model U5G-Max-Outdoor
Networking interface (1) 2.5 GbE RJ45 port; 5G NR and LTE radio
SIM (1) Nano SIM; (1) Nano-SIM or eSIM
Antenna gain Peak 9 dBi, 85° x 85°
Peak data speed (5G NSA) Downlink 3.4 Gbps; Uplink 560 Mbps
5G NR bands n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n71, n75, n76, n77, n78, n79
4G LTE bands B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71
Power method PoE
Max. power consumption 14.5W
Weatherproofing IPX6; IP67 (with cable-gland door kit)
Dimensions 220 x 165 x 66.9 mm (8.7 x 6.5 x 2.6″); with mount: 220 x 165 x 122 mm (8.7 x 6.5 x 4.8″)
Weight Device: 1.2 kg (2.6 lb); Mount: 130 g (4.6 oz)
Mounting Pole mount, wall mount (Included)
Enclosure material Aluminum-alloy, UV-stabilized polycarbonate
Operating temperature -40 to 65 °C (-40 to 149 °F)
NDAA compliant Yes

Check your intended carrier’s bands against the list above before ordering the UniFi 5G Max Outdoor, and aim the antenna during commissioning using the signal readings in UniFi Network.
