U7-PRO-XGS-B

UniFi U7 Pro XGS Access Point Black (U7-PRO-XGS-B)

Bring flagship WiFi 7 performance to the most demanding spaces. The U7 Pro XGS is a ceiling-mounted 8-stream WiFi 7 access point with dedicated spectral scanning, engineered for high-density enterprise and prosumer networks where speed, capacity, and reliability can’t be compromised finished in a sleek black to blend into modern ceilings.

Built on the WiFi 7 (802.11be) standard, it delivers tri-band connectivity across 2.4, 5, and 6 GHz, reaching maximum data rates of up to 8.6 Gbps on 5 GHz and 5.8 Gbps on 6 GHz with channel bandwidths up to 320 MHz. Its 8 spatial streams and MU-MIMO architecture keep throughput high even under heavy load, comfortably serving 500+ connected devices across a coverage area of roughly 160 m² (1,750 ft²).

What sets it apart is a dedicated spectral scanning radio, providing real-time spectral analysis for smarter channel selection and a more stable connection without borrowing capacity from client-serving radios. A multi-gigabit RJ45 port with 10/5/2.5/1 GbE support ensures the wired backhaul keeps pace with WiFi 7 speeds, and the unit powers over a single cable via PoE++. Add seamless management through the UniFi Network platform, and you get enterprise-grade wireless that’s genuinely simple to deploy and monitor.

Key features

• Ceiling- and wall-mountable WiFi 7 (802.11be) access point in black
• 8 spatial streams with tri-band 2.4 / 5 / 6 GHz operation
• Max data rates up to 8.6 Gbps (5 GHz) and 5.8 Gbps (6 GHz), 320 MHz channels
• Dedicated spectral scanning radio for real-time spectral analysis and optimal channel selection
• Handles 500+ connected devices across ~160 m² (1,750 ft²) coverage
• Multi-gigabit RJ45 port with 10/5/2.5/1 GbE support
• Powered via PoE++ over a single Ethernet cable
• MU-MIMO, band steering, and 802.11r fast roaming
• Centrally managed through the UniFi Network platform
