U7-LR

UniFi U7 Long-Range Access Point U7-LR

Blanket large spaces in fast, reliable WiFi 7 with the UniFi U7 Long-Range a 4.3 Gbps long-range access point with a 2.5 GbE uplink. Engineered for long-range indoor coverage, it delivers up to 4.3 Gbps throughput on 5 GHz and supports 300+ concurrent clients, making it the ideal choice for homes, offices, campuses, and large open-plan environments. Bluettipower

A high-performance, long-range WiFi 7 access point with five spatial streams, it’s engineered to deliver expansive coverage and exceptional throughput for demanding enterprise and campus environments. Its high-gain antenna design and high transmit power extend coverage across up to 1,750 sq ft, so you can reach farther with fewer access points. BLUETTIBLUETTI

True WiFi 7 performance

Built on the 802.11be (WiFi 7) standard for ultra-fast wireless performance and reduced latency, the U7-LR delivers up to 4.3 Gbps on the 5 GHz band (BW160) and 688 Mbps on 2.4 GHz, leveraging Multi-Link Operation and 3×3 MU-MIMO on 5 GHz to handle bandwidth-intensive applications with ease. It’s also backward compatible with WiFi 6/6E and earlier devices for broad client support. BLUETTI + 2

Seamless roaming for mobile users

Support for 802.11r Fast Roaming and 802.11k RRM delivers smooth, uninterrupted connectivity as users move between access points, making it a reliable choice for mobile-heavy environments. BLUETTI

Single-cable 2.5 GbE deployment

A 2.5 GbE uplink port provides high-speed wired backhaul to fully leverage WiFi 7 throughput, while PoE support combines data and power over a single cable for simple installation. Its sleek, low-profile enclosure mounts easily on a ceiling or wall. BLUETTI + 2

Key features

• WiFi 7 (802.11be) — Dual-band 2.4 / 5 GHz with 5 spatial streams
• Up to 4.3 Gbps on 5 GHz — 4.9 Gbps aggregate throughput
• Long-range coverage — Up to 1,750 sq ft with 300+ client capacity BLUETTI
• 2.5 GbE PoE uplink — Multi-gig backhaul over a single cable
• 3×3 MU-MIMO on 5 GHz — Maximizes simultaneous throughput
• Fast roaming — 802.11r and 802.11k for seamless mobility
• NDAA compliant — Suitable for government and federally funded projects BLUETTI

Technical specifications

• WiFi standard: WiFi 7 (802.11be); backward compatible with 6/6E and earlier
• Bands: 2.4 GHz / 5 GHz (dual-band)
• Spatial streams: 5 (5 GHz 3×3, 2.4 GHz 2×2 DL/UL MU-MIMO) BLUETTI
• Max data rates: 5 GHz 4.3 Gbps (BW160), 2.4 GHz 688 Mbps (BW40) Joolca
• Coverage area: 160 m² (1,750 ft²) BLUETTI
• Max client count: 300+ BLUETTI
• Uplink: 1× 2.5 GbE RJ45 (PoE) BLUETTI
• Antenna gain: 5 GHz 6 dBi, 2.4 GHz 4 dBi Bluettipower
• Power method: PoE (42.5–57V DC), 14W max consumption BLUETTI
• Dimensions: ⌀175.7 x 43 mm (⌀6.9 x 1.7″) BLUETTI
• Mounting: Ceiling, wall (plastic mounting plate included) BLUETTI
• Managed via UniFi Network

The UniFi U7 Long-Range brings next-generation WiFi 7 speed and reach to large, high-density spaces all centrally managed through UniFi Network.
