Description

UISP-R The UISP Router is a fanless PoE router featuring (8) GbE RJ45 ports and (1) 1G SFP port for an additional fiber uplink option

This router provides a cost-effective routing solution for service providers looking to quickly and inexpensively deliver Gigabit wireless speeds to their customers. With its hefty 110W total PoE supply, the UISP Router delivers substantial power to every radio in your service network. The UISP Router is managed with the UISP application, a centralized platform where you can monitor and manage all of your UISP devices.

  • (8) GbE RJ45 ports with 27V passive PoE that support 2-pair and 4-pair modes
  • 1G SFP port
  • 110W PoE supply when powered with the included AC/DC adapter
  • Fanless, thermal cooling for silent operation
  • Wall-mountable (kit included)
  • Easy, Bluetooth-powered setup via the UISP Mobile app

Managed with the UISP application

Works with Ubiquiti Internet Service Provider (UISP®) application
Centrally manage your networks and clients with ease.
Organize your clients’ plans, setup billing and invoicing, and grow your customer base.
View network topology, advanced data analytics, and more.
Set up devices quickly and manage them on the go with a powerful mobile app.
And much more

Mechanical
Dimensions210.4 x 95 x 29 mm (8.28 x 3.74 x 1.14″)
Weight600 g (1.32 lb)
Enclosure materialPolycarbonate
Hardware
Networking interface(8) 10/1001000 MbE RJ45 ports
(1) 1G SFP port
Management interfaceEthernet in-band
Bluetooth BLE
ProcessorDual-core 880 MHz, MIPS1004Kc
Memory512 MB DDR3
Onboard flash storage512 MB NAND
Power methodExternal AC/DC adapter
Power supply27VDC, 4.4A power adapter (included)
Supported voltage range24 – 28VDC
Max. power consumption10W (excludes PoE output)
ESD/EMP protectionAir: ± 15 kV, contact: ± 8 kV
Operating temperature-10 to 50° C (14 to 122° F)
Operating humidity5 to 95% non-condensing
CertificationsCE, FCC, IC
PoE
PoE interface(8) 27V passive PoE: 2-pair (pins 4, 5+/7, 😎 or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 😎
Max. Passive PoE wattage per port30W/27VDC
Passive PoE voltage range27VDC
LEDs
SystemStatus
RJ45 data portsPoE
Speed/link/activity
SFP data portLink/activity
Additional information
