USW-PRO-XG-48

UniFi Switch Pro XG 48 USW-PRO-XG-48

Built for the most demanding high-density networks, the UniFi Switch Pro XG 48 is a professional-grade 48-port Layer 3 Etherlighting switch with (32) 10 GbE, (16) 2.5 GbE, and (4) 25G SFP28 ports. It combines massive multi-gig capacity with true edge routing and ultra-fast fiber aggregation the ideal backbone for data centres, enterprise cores, and bandwidth-intensive deployments.

With 32 10 GbE and 16 2.5 GbE RJ45 ports plus four 25G SFP28 uplinks, it delivers exceptional throughput and flexibility, while a switching capacity of 920 Gbps, 460 Gbps total non-blocking throughput, and a 684 Mpps forwarding rate keep even the busiest networks running without bottlenecks. UbiquitiUbiquiti

As a true Layer 3 switch, it brings advanced routing to the edge. It supports advanced Layer 3 features such as DHCP server/relay, inter-VLAN routing, and static routing, while Layer 2 capabilities include LACP, STP/RSTP, QoS, IGMP snooping, and comprehensive access control. PROVANTAGE

Management is visual and intuitive. A 1.3″ touchscreen, AR management, and Etherlighting LED indicators make monitoring and troubleshooting effortless, and the whole system is centrally managed through UniFi Network. PROVANTAGE

Key features

• High-density multi-gig connectivity — 32× 10 GbE and 16× 2.5 GbE RJ45 ports for high-speed device support
• 25G fiber uplinks — 4× 25G SFP28 uplinks for ultra-fast fiber aggregation PROVANTAGE
• True Layer 3 routing — Inter-VLAN routing, static routing, and DHCP server/relay at the switch
• Etherlighting + touchscreen — Visual port diagnostics and a 1.3″ front display for at-a-glance management
• Redundant power support — DC power backup redundancy for maximum uptime Flytec
• Enterprise scale — 32,000-entry MAC address table and support for 1,000 VLANs Flytec

Technical specifications

• Port layout: 16× 2.5 GbE RJ45 (2.5G/1G/100M/10M), 32× 10 GbE RJ45 (10G/5G/2.5G/1G/100M/10M), 4× 25G SFP28 (25G/10G/1G) Flytec
• Switching capacity: 920 Gbps
• Non-blocking throughput: 460 Gbps
• Forwarding rate: 684 Mpps
• Dimensions: 442 x 480 x 44 mm (17.4 x 18.9 x 1.7″) Flytec
• Form factor: Rack mount (1U) Flytec
• Weight: 7.5 kg (16.5 lb) without mounting brackets Ubiquiti
• IPv4 static routes: 512; packet buffer 8 MB Flytec
• Redundancy: DC power backup
• Managed via UniFi Network
