The Ubiquiti UniFi U7 Outdoor is an all-weather WiFi 7 access point with 4 spatial streams, an integrated directional super antenna and versatile mounting options. Ubiquiti pairs a high-gain directional array with external omni antennas in one housing, so a single unit can either throw coverage down a long yard, driveway or sports field, or spread it evenly across a courtyard. It suits car parks, outdoor dining and bar areas, campgrounds, orchards, depots and yards — anywhere an indoor access point shooting through a wall or window would not hold up.
Key features
- Dual-band WiFi 7 with 4 spatial streams, rated by Ubiquiti at up to 4.3 Gbps on 5 GHz (BW240) and 688 Mbps on 2.4 GHz (BW40)
- Integrated directional antenna — 12.5 dBi over a 45° x 45° pattern on 5 GHz, 8 dBi over 90° x 90° on 2.4 GHz — plus external omni antennas for wide-area coverage
- Rated by Ubiquiti for 250+ concurrent clients across a 465 m² (5,000 ft²) coverage area
- 1/2.5 GbE RJ45 port providing a 2.5 GbE uplink
- Power method is PoE+, drawing up to 19W from an 802.3at switch port or injector
- IPX6 weatherproofing and a -30 to 60° C operating range
- Wall and pole mounts included; pole diameter 25–60 mm, with wind loading rated at 74.6 N at 200 km/h
- UV-stabilised polycarbonate and aluminium alloy enclosure; NDAA compliant
Specifications
| Model | U7-Outdoor |
| WiFi standard | WiFi 7 |
| Spatial streams | 4 |
| Max. data rate | 5 GHz: 4.3 Gbps (BW240); 2.4 GHz: 688 Mbps (BW40) |
| Networking interface | (1) 1/2.5 GbE RJ45 port |
| Uplink | 2.5 GbE |
| Coverage area | 465 m² (5,000 ft²) |
| Max. client count | 250+ |
| Antenna gain (directional) | 5 GHz: 12.5 dBi, 45° x 45°; 2.4 GHz: 8 dBi, 90° x 90° |
| Antenna gain (external omni) | 5 GHz: 4 dBi, 360° x 30°; 2.4 GHz: 3 dBi, 360° x 30° |
| Max. TX power | 5 GHz: 26 dBm; 2.4 GHz: 23 dBm |
| Power method | PoE+ |
| Max. power consumption | 19W |
| Supported voltage range | 42.5–57V DC |
| Weatherproofing | IPX6 |
| Dimensions | 170 x 208 x 54.5 mm (6.7 x 8.2 x 2.1″) |
| Weight | 1.2 kg (2.6 lb) |
| Mounting | Wall, Pole (Mounts Included) |
| Pole mount diameter | 1–2.36″ (25–60 mm) |
| Wind loading | 74.6 N at 200 km/h (16.8 lbf at 125 mph) |
| Enclosure material | UV-stabilized polycarbonate, aluminum alloy |
| Operating temperature | -30 to 60° C (-22 to 140° F) |
| Operating humidity | 5 to 95% noncondensing |
| NDAA compliant | Yes |
Plan the UniFi U7 Outdoor around its directional pattern — aimed along the area you need to cover, it will outperform an omni access point mounted in the same spot.
