Ubiquiti UNVR Enterprise NVR, 4 x 2.5/3.5 in HDD Bays, Raid 1, Raid 5, UniFi Protect

Ubiquiti UNVR Enterprise NVR – High-Capacity, Scalable Surveillance Storage for New Zealand Businesses

The Ubiquiti UNVR Enterprise is a powerful enterprise-grade network video recorder that seamlessly combines scalable storage, advanced data protection, and the intuitive UniFi Protect software. Designed for Kiwi businesses that demand reliability, security, and flexibility, this NVR supports up to four 2.5”/3.5” HDD bays and offers RAID 1 and RAID 5 configurations for maximum data safety. Whether you’re monitoring a small office or a large multi-site operation, the UNVR Enterprise delivers high-performance video storage with easy Plug-and-Play setup and remote access from anywhere in NZ.

Key Features & Benefits

Enterprise-Class Storage with RAID Protection

With four hot-swappable drive bays supporting up to 8TB each, the UNVR can store up to 30 days of 4K video for 15 cameras or Full HD video for 50 cameras in RAID 5 mode. The system also supports RAID 1 for maximum redundancy, ensuring your surveillance data remains safe even if a drive fails.

Seamless UniFi Protect Integration

The UNVR comes preloaded with UniFi Protect software, offering an intuitive interface accessible from desktop, web browsers, or mobile devices (iOS and Android). Manage, view, and review your security footage with ease without ongoing cloud fees.

High-Speed Connectivity

Equipped with a 10G SFP+ port and a Gigabit RJ45 port, the UNVR ensures ultra-fast data transfer speeds, perfect for high-resolution video streams from multiple cameras.

Flexible Deployment Options

The 1U rackmountable design (kit included) allows for easy installation in professional setups. It also supports USP-RPS (Ubiquiti SmartPower Redundant Power System) for PSU failover, ensuring uninterrupted operation.

Secure Local Video Storage

Your recordings stay on your own secure hardware, giving you complete control over your data and avoiding reliance on third-party cloud servers.

Scalable for Future Needs

The UNVR supports stackable configurations (coming soon), enabling you to multiply storage capacity as your surveillance requirements grow.

Technical Specifications

Dimensions : 442.4 x 325 x 43.7 mm
Weight : Without Rackmount Brackets 5.11 kg , With Rackmount Brackets 5.20 kg
Enclosure Characteristics : SGCC Steel
Processor : Quad-Core ARM Cortex-A57 at 1.7 GHz
System Memory : 4 GB DDR4
On-Board Flash Storage : SPI NOR 32 MB, USB Flash 8 GB
Max. Power Consumption : 100W
Max. Power Budget for Drives : 75W
Power Method : (1) Universal AC Input, (1) RPS DC Input
Power Supply : 100-240VAC, 50/60 Hz, 2A
Networking Interfaces : (1) 10/100/1000 Mbps RJ45 Ethernet, (1) 1/10 Gbps SFP+ Ethernet
Management Interface : Ethernet In-Band Management
ESD/EMP Protection : Air: ± 12kV, Contact: ± 8kV
Operating Temperature : -5 to 40° C
Operating Humidity : 5 – 95% Noncondensing

Ideal Applications in New Zealand

• Corporate Offices – Securely store high-resolution footage for compliance and monitoring.

• Retail Stores – Maintain reliable surveillance storage for theft prevention.

• Industrial Sites – Manage multiple high-definition camera feeds without performance drops.

• Schools & Institutions – Archive video data safely while keeping it accessible for review.

FAQs

Q1: How many cameras can the Ubiquiti UNVR Enterprise support?

A: In RAID 5 with four 8TB drives, it can store 30 days of 4K footage for 15 cameras or Full HD footage for up to 50 cameras.

Q2: Does the UNVR Enterprise work without the internet?

A: Yes. All video is stored locally, and UniFi Protect can be accessed over your local network without internet access.

Q3: Can I expand storage in the future?

A: Yes. Ubiquiti is introducing stackable configurations to increase capacity as needed.

Q4: Is there a subscription fee for UniFi Protect?

A: No. UniFi Protect is included at no extra cost, and all storage is local to your device.

Q5: Can the UNVR Enterprise be rack-mounted?

A: Yes, it comes with a 1U rackmount kit for professional installations.

Q6: Does it support redundant power supply?

A: Yes, it supports USP-RPS for PSU failover to keep your system running during power supply issues.
