Ubiquiti PBE-5AC-620 – 29dBi High-Gain 5GHz PowerBeam AC Bridge for Long Range Wireless Networks

The Ubiquiti PBE-5AC-620 PowerBeam AC is built for powerful, long-range wireless communication. With a 620mm dish reflector, integrated InnerFeed design, and airMAX ac technology, this device delivers exceptional point-to-point performance with throughput speeds of 450+ Mb/s and coverage extending beyond 30 km. It’s an ideal solution for professional wireless ISPs, rural broadband distribution, or large-scale remote monitoring systems in New Zealand.

Key Features & Benefits

Ultra-Long Range Wireless Performance

Engineered for long-distance links, the 29 dBi high-gain dish provides strong signal focus and low noise interference. It’s perfect for bridging sites across wide open areas, hills, or rural landscapes in NZ.

High-Speed Data Transmission

With a 720 MHz Atheros MIPS processor and 128MB DDR2 RAM, the PBE-5AC-620 supports throughput speeds up to 450+ Mbps, enabling reliable voice, video, and data transfer over long distances.

Advanced airMAX ac Technology

The PowerBeam uses airMAX ac with custom silicon and TDMA scheduling to improve latency, scalability, and channel efficiency. Ideal for high-demand, multi-user network setups.

InnerFeed Technology

The integrated radio eliminates the need for cables between the antenna and radio. This reduces signal loss and simplifies installation resulting in cleaner, more efficient performance.

airOS v7 for Network Management

airOS 7 provides a user-friendly interface for configuring, monitoring, and managing device performance. Advanced tools like spectrum analysis and RF diagnostics are built-in.

Robust Construction for Harsh Environments

Built to operate in outdoor, remote, or industrial locations, the PowerBeam AC features rugged components and weather-resistant design for long-term reliability in NZ conditions.

Technical Specifications

• Model: PBE-5AC-620

• Processor: Atheros MIPS 74Kc, 720 MHz

• Memory: 128 MB DDR2 RAM / 8 MB Flash

• Operating Frequency: 5 GHz

• Antenna Gain: 29 dBi

• Dish Diameter: 620 mm

• Max Throughput: 450+ Mbps

• Range: 30+ km

• PoE Support: Yes (PoE injector required)

• Software: airOS v7

• Technology: airMAX ac, InnerFeed

• Operating Mode: Point-to-Point (PtP), CPE

Applications

• Wireless backhaul across valleys or large farms

• Rural broadband deployment across NZ

• High-speed connectivity for remote CCTV or sensor networks

• Outdoor point-to-point wireless bridging for ISPs

• Campus or multi-site network extension

Frequently Asked Questions (FAQs)

What is the range of the PBE-5AC-620?

The PowerBeam PBE-5AC-620 supports 30+ km range under optimal line-of-sight conditions, making it ideal for long-distance point-to-point wireless bridging.

Does the PBE-5AC-620 require an external antenna?

No, it includes a 29dBi dish antenna and uses InnerFeed technology, which integrates the radio directly into the feedhorn, eliminating the need for external cabling.

Is the PBE-5AC-620 suitable for rural NZ installations?

Yes, it’s widely used in rural broadband, remote video surveillance, and wireless ISP deployments across New Zealand due to its high performance and long-range capacity.

What is the maximum data throughput?

The PBE-5AC-620 supports 450+ Mbps, depending on configuration, environmental interference, and channel width.

What’s the difference between airMAX and airMAX AC?

airMAX AC is the newer generation, offering higher speeds, better scalability, and improved latency using advanced modulation and custom silicon acceleration.
